Products Description
Model A45D–3W IP65 Mini LED Spotlight with Clamp
Compact Size,Powerful Performance–Ideal for Architectural&Landscape Accent Lighting
The Model A45D 3W Mini LED Spotlight is designed to bring your outdoor lighting projects to life.Whether you're highlighting architectural details,accentuating garden features,or creating dynamic color-changing displays,this compact yet powerful fixture delivers exceptional performance in a sleek,low-profile design.
With DMX512 control and RGB/RGBW color options,you have full creative freedom to customize lighting effects for any project.The spotlight supports multiple installation methods—clip,spike,or clamp mounts—making it incredibly versatile for a wide range of applications.
Built to endure the elements,the A45D features a die-cast aluminum housing with UV-resistant paint and an IP65 waterproof rating,ensuring reliable,long-lasting performance even in harsh outdoor conditions.
Key Features
3W Power Consumption–Energy-efficient yet powerful illumination
DMX512 Control–Full-color RGB/RGBW with dynamic effects
Premium LEDs–CREE or OSRAM chips with 90+Lumens per Watt
Multiple Beam Angles–6°/10°/15°/20°/30°/45°/60°optics available
Versatile Mounting–Clip,spike,and clamp options for flexible installation
Durable Construction–Die-cast aluminum alloy+tempered glass
Weatherproof–IP65 rated,UV-resistant paint for outdoor use
International Certifications–TUV,CE,RoHS,UL
Technical Specifications
Parameter | Details |
Model No. | A45D |
Input Voltage | AC220V/DC24V |
Power Factor | >0.9 |
Power Consumption | 3W |
LED Brand | OSRAM or CREE |
LED Lifetime | >50,000 hours |
Color Options | 1800K–6000K/Single Color/RGB/RGBW |
CRI | Ra>80 |
Luminous Flux | 240 lm |
Beam Angle | 6°/10°/15°/20°/30°/45°/60° |
Control | ON/OFF or DMX512 |
Main Material | Die-cast Aluminum+Tempered Glass |
Shell Color | RAL7012(Anthracite Gray) |
Dimensions | Ø47×L80×H257 mm |
Weight | 0.4 kg |
IP Rating | IP65 |
Mounting | Spike for ground installation(clip/clamp also available) |
Working Temperature | -20°C~+45°C |
Storage Temperature | -30°C~+50°C |
Humidity | 15%~90%RH |
Certifications | CE,RoHS |
Applications
Architectural Accent Lighting–Highlight columns,facades,and structural details
Garden&Landscape Lighting–Uplight trees,illuminate pathways,accent shrubs
Commercial Displays–Perfect for outdoor retail,restaurants,and hospitality
Residential Gardens–Create ambiance in patios,yards,and driveways
Event&Dynamic Lighting–RGB/RGBW with DMX control for color-changing effects
Why Choose Model A45D?
Design Flexibility–Multiple mounting options and beam angles to suit any project
Color Versatility–From warm white to full-color RGBW,all DMX controllable
Built to Last–Premium materials and IP65 protection ensure years of reliable service
Trusted Quality–Certified to international standards(TUV,CE,RoHS,UL)
Elevate your outdoor lighting projects with the Model A45D–where compact design meets professional-grade performance.
Selection Guide
The A45D clamp-mounted 3W version is suitable for railing edges, pergolas, fences, display structures, and other locations where drilling into the ground is not practical. It is a good option when a project needs a very small fixture with flexible mounting and subtle RGB/RGBW accent output.
