Products Description
WL5 Series LED Square Wall Spotlight
Outdoor Wall-Mounted Spotlight | 6W / 12W | IP65 | Square Design
Product Overview
The WL5 Series is a modern range of outdoor wall-mounted spotlights featuring a sleek square design. Available in two models with 6W and 12W power options, these luminaires deliver focused, directional illumination for garden walls, garage entrances, corridors, and building facades. With IP65 waterproof rating and durable aluminum construction, the WL5 Series combines contemporary aesthetics with reliable outdoor performance.
Series Models
| Model | Power | Design | Typical Applications |
|---|---|---|---|
| WL5-S80 | 6W | Single-head square spotlight | Garage entrances, corridor walls, residential accents |
| WL5-D80 | 12W | Double-head square spotlight | Garden walls, building facades, commercial entrances |
Key Features
Two Power Options
WL5-S80 (6W) for accent lighting, WL5-D80 (12W) for enhanced brightness and wider coverage.Square Modern Design
Clean, geometric aesthetic that complements contemporary architecture and landscape designs.IP65 Waterproof Rating
Fully protected against dust and low-pressure water jets, ensuring reliable performance in all weather conditions.Durable Aluminum Construction
High-quality aluminum housing with excellent corrosion resistance and thermal management.Multiple Beam Angle Options
Available in 15°, 30°, and 45° beam angles for precise accent lighting control.Color Temperature Options
Available in warm white (WW), cool white (CW), and daylight (DL) to suit different project requirements.Dimmable
Compatible with standard dimming systems for flexible lighting control.
Technical Specifications
| Specification | WL5-S80 | WL5-D80 |
|---|---|---|
| Power | 6W | 12W |
| Light Source | LED | LED |
| Luminous Efficacy | ≥85 lm/W | ≥85 lm/W |
| Luminous Flux | 510 lm | 1020 lm |
| Color Temperature | WW / CW / DL | WW / CW / DL |
| Color Rendering Index (CRI) | ≥80 | ≥80 |
| Beam Angle | 15° / 30° / 45° | 15° / 30° / 45° |
| Input Voltage | AC 220V ±10% | AC 220V ±10% |
| Waterproof Rating | IP65 | IP65 |
| Material | Aluminum | Aluminum |
| Installation | Wall Mount | Wall Mount |
| Dimmer Support | Yes | Yes |
| Lifespan | ≥30,000 hours | ≥30,000 hours |
| Warranty | 3 Years | 3 Years |
| Working Temperature | -20°C to +55°C | -20°C to +55°C |
| Product Weight | ~1 kg | ~1.5 kg |
Beam Angle Options
| Beam Angle | Effect | Best For |
|---|---|---|
| 15° | Narrow spot | Highlighting specific objects, signage, sculptures |
| 30° | Medium flood | Accent lighting on walls, entrances, columns |
| 45° | Wide flood | General illumination, pathway walls, large surfaces |
Color Temperature Options
| Color | CCT | Effect | Best For |
|---|---|---|---|
| Warm White (WW) | 2700K–3000K | Cozy, welcoming ambiance | Residential gardens, entrances, traditional architecture |
| Cool White (CW) | 4000K–5000K | Clean, bright illumination | Commercial buildings, garages, security lighting |
| Daylight (DL) | 5000K–6500K | Crisp, high visibility | Modern architecture, signage, task lighting |
Applications
Garden walls and landscape features
Garage entrances and driveways
Corridor and pathway walls
Building facade accent lighting
Residential and commercial entrances
Architectural detailing
Signage and object highlighting
Selection Guide
WL5 Series is suited to projects that need a more directional wall-mounted accent effect on facades, entry walls, garage surrounds, courtyards, and exterior corridors. It is a strong choice when a square fixture style is preferred and the lighting design needs both architectural presence and durable outdoor construction.
